Technical Specifications

Warranty Lifetime

Number of Conductors 14

Connector Plating Nickel

Cable Jacket Type PVC - Polyvinyl Chloride

Cable Shield Type Aluminum-Mylar Foil with Braid

Fire Rating CMG Rated (General Purpose)

Number of Ferrites 1

Regulatory Approvals UL2919

Connector A 1 - VGA (15 pin; High Density D-Sub) Male

Connector B 1 - VGA (15 pin; High Density D-Sub) Male

Impedance 75 Ohm

Color Black

Wire Gauge 28 AWG

Max Connector Dimension 1.3 in [34 mm]

Cable Length 6 ft [1.8 m]

Cable OD 0.4 in [9 mm]

Product Length 6 ft [1.8 m]

Product Weight 9.9 oz [280 g]

Operating Temperature 0 to 60 °C

Storage Temperature -20 to 80 °C

Humidity 0 - 80 %RH

Shipping (Package) Weight 0.6 lb [0.3 kg]

Included in Package 2 - Nuts

Included in Package 1 - 6 ft Coax High Resolution Monitor VGA Cable - HD15 M/M

Certifications, Reports and Compatibility
