System Requirements

Console Side

One VGA, SVGA or Multisync monitor

One USB keyboard

One USB mouse

Computer Side

Each USB enabled computer must be connected to the

StarView switch by:

One HDB15 male-to-female VGA cable or monitor

One USB A-B cable with Type-A and Type-B plug for

USB devices, as shown in figure 1.

figure 1: USB A-B cable

(Note: An optional HDB-15 to DB-15 VGA adapter is

required for Mac computer VGA ports)
