Computer Connection

Use a HDB15 male-to-female cable to connect from a

computer’s VGA port to the StarView’s VGA port of the

PC side, as shown in figure 3.

Use a USB A-B cable to connect from the StarView’s

USB port on the corresponding computer (A connector is

the flat connector) as shown in figure 3.

Figure 3: Computer Connection
